Rigid-flex PCB

TopFast provides Rigid-flex PCB services tailored to meet customer’s needs. Full design support, fabrication, layout optimization, and assembly. Ensure that your Rigid-flex PCBs are manufactured to the highest standards, using the most advanced technologies.

For PCB Prototype or Assembly

Why Use a Rigid-flex PCB?

Rigid-flex PCBs offer many advantages over traditional rigid PCBs. One of the most significant advantages is a reduction in solder joints, which ensures higher connection reliability. Additionally, using Rigid-flex PCBs offers space-saving and cost advantages compared to rigid PCBs, as fewer components and less materials are needed. Furthermore, testing of Rigid-flex PCBs is easier, as all the subcircuits are already interconnected, eliminating the need to test each component separately. Finally, Rigid-flex PCBs are usually fitted into an enclosure, ensuring additional protection and increasing the overall robustness of the PCB.

For Medical instrument and Digital Electronics

What is a Rigid-flex PCB?

A Rigid-flex PCB is a combination of both rigid and flexible substrates. It uses the advantages of rigid and flexible PCBs, and is designed to connect subcircuits on rigid PCBs. The design is created in a 3-dimensional environment allowing for greater circuit complexity and more options for system integration. Rigid-flex PCBs also feature high density laminated structure, hole filling and electroplating, hole stacking, and sheet and surface flatness requirements. These features allow for improved electrical and mechanical performance, as well as land reduction, cost savings, and improved thermal performance.

Receive your PCB Quote

How much cost Rigid-flex PCB?

The cost of Rigid-flex PCBs can vary greatly depending on size, number of layers, and complexity.

More Options

More Options
ASSEMBLY CAPABILITIES

Assembly Capabilities for PCBs

  • Stencil Size Range
  • 29inch*29inch
  • SMT
  • Position accuracy: 25um
    Components size:0201--150mm
    Max.PCB Size:680mm*500mm
    MinPCB size:50mm*50mm
    Min.PCB Thickness:0.3mm-- 6mm
    Min.IC Pitch: 0.30mm
  • Wave-Solder
  • Max.PCB width:450mm Min.PCB width:no Limited Component height: Top 120mm/Bottom 15mm
  • Min.BGA pitch
  • 0.008"
  • Max.BGA Size
  • 74mm x74mm
  • BGA Ball Pitch
  • 1.00mm(Min);3.00mm(Max)
  • BGA Ball Diameter
  • 0.40mm(Min);1.00mm(Max)
  • QFP Lead Pitch
  • 0.38mm(Min);2.54mm(Max)
100+

Metals and Plastics

About MATERIALS

Materials used to manufacture Rigid-flex PCB

A rigid-flex PCB uses two different materials to manufacture a board - flexible polyimide material and FR4 board. Typically, the flexible polyimide material is a heat-resistant film that is laminated onto a copper cladding substrate, forming a flexible layer that is able to bend and stretch while maintaining its structure. The FR4 board is the rigid layer that is placed on top of the flexible material, providing a substrate that is strong, durable, and reliable. The combination of these two materials allows the manufacture of a rigid-flex PCB that is able to flex and bend while still providing the necessary strength to meet the application requirements.


Rigid-flex PCB

Rigid Flex PCB up to 8 flex layers and 16 Max layers

Topfast is a manufacturer specialized in Rigid Flex PCBs. We offer PCB assembly and prototyping up to 8 flex layers and 16 Max layers, providing more efficient performance compared to standard rigid PCBs. This type of PCB is ideal for applications involving complex designs. Topfast offers superior quality flex circuits that are designed to meet the needs of even the most demanding applications, providing a high degree of flexibility and reliability.
